EZ-RJ45 Cat6 Crimp Plugs, 10 pcs - Platinum Tools
Product Code : 100009C
Short Description
Platinum Tools EZ-RJ45 Cat6 Crimp Plugs, Slide Through Wires, 10 Pieces Clamshell
Price
$10.96
Availability
In Stock
Payment Supports:
Discount Table
Increase Quantity to get discount
Quantity
Price
50+
-10.09%
OFF
$9.854
100+
-10.45%
OFF
$9.815
250+
-10.92%
OFF
$9.763
500+
CALL
Overview
Product Code
100009C
Warranty
Lifetime
Connection
RJ45 Male Plug
Wire Gauge
23 - 24 AWG
Weight
0.07 lbs
Product Description
The Platinum Tools EZ-RJ45 cat6 crimp connectors are a great easy way to make your crimps are tight and accurate. The individual wires go all the way through this connector head and allow you to make sure everything is lined up before you crimp down. Specifically made to work with crimp tool 100054C or the EXO crimp tool frame with the EZ-RJ45 die part number 100072C.
Details
Details
- Max Cable Outer Diameter: 0.275” (6.98mm)
- Max Insulation Diameter (Conductors): 0.040” (1.016mm)
- Meets ANSI/EIA/TIA/TAA specifications
- Solid or Stranded, 24 – 23 AWG
- UL Listed and RoHS/FCC compliant
- 50 micron gold plated contacts
- 1,000 Mating Cycles
- Operating Temperature: -40C to 85C
- Color: Clear/Transparent
- Made in USA
©
