This 1 meter (~3 feet) fiber optic cable is terminated with LC/UPC (Lucent Connector - Ultra Physical Contact) and SC/APC (Subscriber Connector - Angled Physical Contact) connectors. It is an OS2 singlemode fiber (9 micron core) designed for fast Ethernet, fiber channel, gigabit Ethernet, data center, ATM and other data applications typically involving longer distances. The cord is duplex (two fibers) which means it permits synchronous communication between devices, the clip on the connectors can be removed for simplex applications or to support non standard duplex widths. The cladding diameter is 125 microns. OFNR (riser) rated fiber cable is ideal for use in upright shafts that run between floors.

• Length: 1 meter
• Fiber Connector : LC to SC
• Polish Type: UPC to APC
• Fiber Mode: OS2, Singlemode, 9 / 125 μm


• Wave Length: 1310nm & 1550nm
• ITU-T standard G657A1 Compliant
• Insertion Loss: SC/APC ≤ 0.3 dB, LC/UPC ≤ 0.2 dB
• Return Loss: SC/APC ≥ 65 dB, LC/UPC ≥ 55 dB
• Jacket OD: 2.0*4.1mm
• Jacket Material: OFNR (Riser)
• Jacket Color: Yellow
