1x8 PLC with Fan Out and SC/UPC Connectors
Product Code : 15F2-20108
Short Description
1x8 PLC with Fan Out and SC/UPC Connectors.
Price
$64.87
Availability
Limited - Contact Before Order
Payment Supports:
Discount Table
Increase Quantity to get discount
Quantity
Price
10+
-10%
OFF
$58.383
25+
-10.1%
OFF
$58.318
50+
-10.2%
OFF
$58.253
100+
CALL
Overview
Product Code
15F2-20108
Warranty
1 year manufacturer's warranty
End 1
SC/UPC Simplex Connector
End 2
8 x SC/UPC Male Connectors
Length
1.2 meters
Connector
Blue
Weight
0.50 lbs
Product Description
Today's high-port-count applications for broadband system applications demand the best performance and the highest reliability under the most adverse of environments. Planar Lightwave Circuit Splitters deliver on all these requirements. We provide a variety of PLC's. The PLC is a device used to divide one or two light beams to multiple light beams uniformly or combine multiple light beams to one or two light beams. This unit is pre-terminated with 8 SC/UPC connectors.
Features- Very low insertion loss
- Broad operation
- Low PDL
- High reliability and Stability
- Passed Telcordia GR-1209-CORE and GR-1221-CORE
- RoHS Compliant
- Operating Wavelength: 1260nm - 1650nm
- Insertion Loss (dB) MAX (P/S):10.5/11
- Uniformity (dB) MAX (P/S): 0.5
- Return Loss MIN (P/S): 50/55
- Loss (dB) MAX (P/S): 0.3/0.1
- Directivity MIN (P/S): 55
- Fiber Type: SMF-28e
- Wavelength Dependent Loss (dB): 1.0
©
