The Cisco Compatible 1000BASE-LX/LH SFP Transceiver Module is a high-performance, cost-effective solution for single-mode fiber (SMF) communications. Operating at a typical wavelength of 1310nm, this module ensures reliable data transmission over distances up to 30 kilometers. It features a standard simplex connector and is fully compliant with TAA requirements.

• Hot-Pluggable SFP 20-Pin Connector: Allows seamless installation and removal without network interruption.
• High-Performance Transmitter: Utilizes a 1310nm Vertical Cavity Surface Emitting Laser (VCSEL) housed in a durable plastic barrel package. Compliant with IEC-60825-1:2014, EN60825-1:2014/A11:2021, and FDA 21 CFR 1040.10 and 1040.11 safety standards.
• Advanced Receiver: This receiver features a GaAs PIN photodiode coupled with a high-sensitivity trans-impedance amplifier (TIA) and post-amplifier IC, ensuring robust performance with Signal Detection (SD) or Loss of Signal (LOS) indication.
• Single +3.3V Power Supply: Provides reliable power with differential inputs and outputs.
• MSA Compliant: Meets the standards for Small Form Factor Pluggable (SFP) Multi-Source Agreement (MSA) and SFF-8472 MSA Digital Diagnostic Monitoring (DDM) with internal calibration.
• Wide Operating Temperature Range: Commercial operation from 0°C to +70°C and industrial operation from -40°C to +85°C.
• RoHS Compliant: Adheres to the Restriction of Hazardous Substances Directive, ensuring environmentally friendly design.

• ATM Switches: Ideal for use in Asynchronous Transfer Mode (ATM) networks.
  Media Converters: Perfect for multimode fiber media conversion applications.
• Backbone Links: Reliable for multimode fiber backbone connections.
• Networking Equipment: Suitable for bridges, routers, intelligent hubs, and concentrators.
• Fast Ethernet: Ensures high-speed Ethernet connectivity.

• International Safety Standards: Class 1 laser compliant with IEC-60825-1:2014, EN60825-1:2014/A11:2021, and FDA 21 CFR 1040.10 and 1040.11.
• RoHS Compliance: Environmentally friendly and safe for use in various applications.

Upgrade your network infrastructure with the Cisco Compatible 1000BASE-LX/LH SFP Transceiver Module, designed for superior performance, safety, and reliability in demanding communication environments.
