LC/UPC to LC/APC OS2 Duplex Fiber Optic Patch Cable, 9/125
Product Code : LCLC-01603
Short Description
LC/UPC to LC/APC OS2 Duplex 2.0mm Fiber Optic Patch Cord, OFNR, Singlemode 9/125, Yellow Jacket, Blue LC + Green LC Connector, 3 meter (10 ft) - Part #: LCLC-01603
Price
$7.55
Availability
Limited - Contact Before Order
Payment Supports:
Discount Table
Increase Quantity to get discount
Quantity
Price
50+
-9.95%
OFF
$6.799
100+
-13.56%
OFF
$6.526
250+
-17.18%
OFF
$6.253
500+
CALL
Overview
Product Code
LCLC-01603
Warranty
Lifetime
End 1
LC/UPC Duplex Connector
End 2
LC/APC Duplex Connector
Length
3 meters
Color
Yellow
Weight
0.10 lbs
Product Description
Specifications:
This 3 meter (~10 feet) fiber optic cable is terminated with LC/UPC (Lucent Connector - Ultra Physical Contact) and LC/APC (Angled Physical Contact) connectors. It is an OS2 singlemode fiber (9 micron core) designed for fast Ethernet, fiber channel, gigabit Ethernet, data center, ATM and other data applications typically involving longer distances. The cord is duplex (two fibers) which means it permits synchronous communication between devices, the clip on the connectors can be removed for simplex applications or to support non standard duplex widths. The cladding diameter is 125 microns. OFNR (riser) rated fiber cable is ideal for use in upright shafts that run between floors.
Specifications:
- Length: 3 meter
- Fiber Connector : LC to LC
- Polish Type: UPC to APC
- Fiber Mode: OS2, Singlemode, 9 / 125 nm
- Wave Length: 1310nm & 1550nm
- ITU-T standard G657A1 Compliant
- Insertion Loss: LC/APC ≤ 0.3 dB, LC/UPC ≤ 0.3 dB
- Return Loss: LC/APC ≥ 65 dB, LC/UPC ≥ 55 dB
- Jacket OD: 2.0*4.1mm
- Jacket Material: OFNR (Riser)
- Jacket Color: Yellow
©
